원래 장소:
중국/심천
브랜드 이름:
Yanbixin
인증:
UL, TUV, CE, CQC, ROHS
모델 번호:
YB21D6-20A-S
연락주세요
1450VDC 10A Low Pass Emi Filter Electromagnetic Interference Filters
10A low pass emi filter lectromagnetic interference filters for industrial electronic equipment
Description:
The emi filter is a filter circuit composed of capacitors, inductors and resistors. The filter can effectively filter out the frequency point of a specific frequency in the power line or the frequency outside the frequency point to obtain a power signal of a specific frequency, or eliminate a power signal of a specific frequency
Feature:
• 3 in 1 compact power entry modules with filtered
• Current rating 1A~10A
• Minified design with narrow body
• With IEC950 appliance inlet and fuse holder and switch
• Power entry model filters with an IEC inlet, a mains filter with dual-fuse holder and a 2-pole rocker switch.
• The rated current can be offered up to 10 amps.
• Custom-specific versions are available on request.
Specification Of EMI Power Filter
|
Item |
single-phase EMI FILTER |
Rated Current |
10A |
|
Model |
YB35D3-10A-Q |
Environmental Temperature |
40°C |
|
Transfer Function |
Low Pass |
Temperature Range |
25 / 085 / 21 |
|
Package Type |
Surface Mount |
Operating Frequency |
50/60HZ |
|
Nominal Center Frequency |
10K-30MHZ |
Line to Line |
1450VDC |
|
Insertion Loss |
50~90dB |
Line to Ground |
2250VDC |
|
Rated Voltage |
250/115VAC |
Maximum Leakage Current |
220VAC/60HZ 3-10mA Max |
|
Flammability corresponding to |
UL 94V-0 |
MOQ |
Negotiable |
|
Lead Time |
7-15 weekday |
Price |
Negotiable |
Applications:
It can be widely used in the power distribution network of industry, commerce, and government organizations, such as: power systems, electrolytic plating companies, water treatment equipment, petrochemical companies, large shopping malls and office buildings, precision electronics companies, airport/port power supply systems, and medical Institutions, etc.
n, great price, excellent, service, fast delivery! Free replacement within three months, free maintenance within six years, life-long maintenance!
Naming Rule:
YB 35-------D3----------10A-------------S/T/B
| | | |
circuit case current connection
S: Screw
T: Terminal Block
B: Copper bar
Electrical Schematic
Drawing:
Factory Picture
Our Services
|
Before-sale |
After-sale |
|
1. All inquires will be replied with 8 hours. 7D/24H service, please feel free to contact us with Email/TM/Skype |
1. All EMI filters will be tested and adjusted before shipping. |
|
2. Strong technical team and professional sales. |
2. After receiving the products, any questions we will try our best to solve. |
|
3. Customized packaging is acceptable. |
3. Free replacement within three months, free maintenance within six years, life-long maintenance! |
|
4. We supply free samples and EMC technical rectification services |
|
FAQ
1. What is its lead time for samples and mass production?
Within 10 work days for samples and 30 days for mass production.
2. How to proceed an order for baseus products?
Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
