Name: Special Type Socket EMI Filter With Fuse And Switch 1A~10A Power Entry Module Filter
Brand: Shenzhen Yanbixin Technology Co., Ltd.
SKU: YB11C7-3A-Q
Price: 4.00 USD
Availability: InStock

집 > 제품 > RFI 여과기를 플러그를 꽂으십시오 >

Special Type Socket EMI Filter With Fuse And Switch 1A~10A Power Entry Module Filter

원래 장소:

중국

브랜드 이름:

YBX

인증:

UL, TUV, CE, CQC, ROHS

모델 번호:

YB11C7-3A-Q

연락주세요

인용문을 요구하세요

제품 상세정보

전압 등급:

115V/250V

현재 등급:

1-10A

누설 전류:

0.4mA 115V/60HZ; 0.4mA 115V/60HZ; 0.8mA 250V/50HZ 0.8mA 250V/50HZ

작동 주파수:

50Hz/60Hz

온도 범위:

-25°C~+100°C

입구 소켓:

IEC 320

재료:

마텔 및 플라스틱

보증 기간:

2 년

HIPORT 등급(1분 동안):

접지에 대한 라인------라인에 대한 2250VDC 라인-------1450VDC

작동 주파수:

400Hz에 대한 DC

그렇게 하기 위해 대응하는 인화성:

UL 94V-0

지불과 운송 용어

최소 주문 수량

100

가격

$1~$8 /PCS

포장 세부 사항

상자 : 56.5*28.5*22.5 (cm); 108pcs/box

배달 시간

10-20 일

지불 조건

t/t, l/c

공급 능력

한 달에 10 만 조각/조각

Special Type Socket EMI Filter With Fuse And Switch 1A~10A Power Entry Module Filter

최상의 가격을 얻으세요

비디오

High Quality A13 IEC Inlet Filter 1A~20A Socket EMI Filter For Data Equipment

최상의 가격을 얻으세요

비디오

YB22A5-20A-Q IEC 입구 EMI 필터 UL 인증 115V 250V 소켓 타입 메인 필터

최상의 가격을 얻으세요

비디오

YB11A5-6A-Q(R) IEC C13 입구 EMI 필터 115V 250V 소켓 타입 전력 필터

최상의 가격을 얻으세요

연락주세요

+86 ‭18118799639‬

alisa@ybx-emc.com

86-755-27147101

지금 접촉하세요

제품 설명

Special Type Socket EMI Filter With Fuse And Switch 1A~10A Power Entry Module Filter

IEC inlet filters YB-C series

Features:

-- Rated currents up to 10A

-- Single fuse holder

-- 2-pole rocker switch

-- General-purpose application

-- Approvals:

Special Type Socket EMI Filter With Fuse And Switch 1A~10A Power Entry Module Filter 0

Rule of Nomination:

YB 11 C7 - 3A - Q ( R5 )

¦ ¦ ¦ ¦ ¦

circuit case current connection optional

Electrical schematic:

Standard type

Special Type Socket EMI Filter With Fuse And Switch 1A~10A Power Entry Module Filter 1

R5 type

Special Type Socket EMI Filter With Fuse And Switch 1A~10A Power Entry Module Filter 2

Tabulates:

Rated Current
@40°C

Terminal Options*

Bleeder resistor

(optional)

Ground
(Optional)

Leakage current 250V/50Hz

Electrical Schematic

Rated Voltage(V)

Operating Frequency(Hz)

Model No.

YB11C7-1A

<0.8mA

Fig.1

115/250V

50/60Hz

YB11C7-2A

Fig.1

YB11C7-3A

Fig.1

YB11C7-4A

Fig.1

YB11C7-6A

Fig.1

YB11C7-8A

Fig.1

YB11C7-10A

10A

Fig.1

YB11C7-1A

Fig.1

YB11C7-2A

Fig.1

YB11C7-3A

Fig.1

YB11C7-4A

Fig.1

YB11C7-6A

Fig.1

YB11C7-8A

Fig.1

YB11C7-10A

10A

Fig.1

Medical Type Tabulates:

Rated Current
@40°C

Terminal Options

Bleeder resistor (optional)R(MΩ)

Medical equipment
(optional)5

Ground (optional)

Leakage current 250V/50Hz

Electrical Schematic

Rated Voltage(V)

Operating Frequency(Hz)

Model No.

YB11C7-1A-x(R5)

<5μA

Fig.2

115/250V

50/60Hz

YB11C7-2A-x(R5)

Fig.2

YB11C7-3A-x(R5)

Fig.2

YB11C7-4A-x(R5)

Fig.2

YB11C7-6A-x(R5)

Fig.2

YB11C7-8A-x(R5)

Fig.2

YB11C7-10A-x(R5)

10A

Fig.2

Special Type Socket EMI Filter With Fuse And Switch 1A~10A Power Entry Module Filter 9 *Q: Fast-on 6.35x0.8mm S: solder 4.0x0.8mm W: UL1015 18awg

Mechanical Dimension(Unit: mm)

C Case

Special Type Socket EMI Filter With Fuse And Switch 1A~10A Power Entry Module Filter 12

YB11C7-10A-Q Product Pictures:

Insertion loss table(In 50ohm system according to IEC/CISPR No.17):

differential mode

1A 3A 6A

Special Type Socket EMI Filter With Fuse And Switch 1A~10A Power Entry Module Filter 14

8A 10A

Special Type Socket EMI Filter With Fuse And Switch 1A~10A Power Entry Module Filter 17

Shipment:

---Shipping terms: DHL, UPS, FedEx, TNT, EMS

---Port is Shenzhen or as requests.

Factory Pictures:

Special Type Socket EMI Filter With Fuse And Switch 1A~10A Power Entry Module Filter 20

Special Type Socket EMI Filter With Fuse And Switch 1A~10A Power Entry Module Filter 21
